MDO Rubber Roller and Nip Roller for Biaxially Oriented Plastic Film Production Line with 13000mm Length and Up to 600m/min Speed

China HUATAO LOVER LTD certificaten
China HUATAO LOVER LTD certificaten
Het Huataobedrijf is een zeer goed bedrijf, ben ik zeer bereid om met u samen te werken, veilig, efficiënt, professioneel, eerlijk, gelukkig! Dank u voor het voorzien van me van de stabiele dienst en producten. -EUROPAT

—— INDUSTRIËLE EUROPT

Ik ben online Chatten Nu

MDO Rubber Roller and Nip Roller for Biaxially Oriented Plastic Film Production Line with 13000mm Length and Up to 600m/min Speed

MDO Rubber Roller and Nip Roller for Biaxially Oriented Plastic Film Production Line with 13000mm Length and Up to 600m/min Speed
MDO Rubber Roller and Nip Roller for Biaxially Oriented Plastic Film Production Line with 13000mm Length and Up to 600m/min Speed MDO Rubber Roller and Nip Roller for Biaxially Oriented Plastic Film Production Line with 13000mm Length and Up to 600m/min Speed MDO Rubber Roller and Nip Roller for Biaxially Oriented Plastic Film Production Line with 13000mm Length and Up to 600m/min Speed

Grote Afbeelding :  MDO Rubber Roller and Nip Roller for Biaxially Oriented Plastic Film Production Line with 13000mm Length and Up to 600m/min Speed

Productdetails:
Plaats van herkomst: China
Merknaam: HUATAO
Certificering: ISO
Modelnummer: Rubberroller
Betalen & Verzenden Algemene voorwaarden:
Min. bestelaantal: 1 st
Prijs: 2000USD/pc-5000USD/pc
Verpakking Details: Houten kisten
Levertijd: 1-3 maanden
Betalingscondities: L/C, T/T
Levering vermogen: 10000 stuks per jaar
Gedetailleerde productomschrijving
Productnaam: MDO-rubberroller voor biaxiaal georiënteerde productielijn voor kunststoffilms Sleutelwoorden: Water verwijdering Nip Roller, MDO Nip Roller, Corona Roller, Corona Nip Roller
Rubbermateriaal: Synthetisch rubber, EPDM, PU, enz. Shell-materiaal: 45# staal, Q345B, enz.
Sollicitatie: Voor BOPP, BOPET filmlijn Rubberkleur: Wit, rood, zwart
Maximale lengte van het gezicht: 13000mm Maximale snelheid: Op tp 600m/min
Markeren:

MDO rubberen rol voor de productie van plastic folie

,

Niprol voor biaxiaal georiënteerde folielijn

,

Industriële rol met een lengte van 13000 mm

MDO Rubber Roller For Biaxially Oriented Plastic Film Production Line
Rubber Roller Basis Information
Biaxially oriented produced的行film, generally the first machine direction orientation and then transverse direction orientation. The basic process is as follows:
  1. Raw material mix: The main raw material required for the production of BOPP film is Mylar masterbatch slice. Polyester chips, also known as polyethylene terephthalate (PET), polyester film masterbatch chips contain silica, titanium dioxide, calcium carbonate and other substances.
  2. Melt extrusion: In the production process of polyester film, it must go through the melt extrusion process. The process equipment used includes extruders,menting pumps and filters.
  3. Casting system: The casting system consists of a die head, a cold roll and an attachment device for the casting sheet. Die head is the key part affecting the thickness and uniformity of the casting.
  4. isse Strapping: MDO (Machine Direction Orientation): The process is processed by rollers, realizing orientation by using the speed difference between rollers. The machine is composed of snareheating roller, MDO stretching roller, MDO nip roller, etc.
  5. TDO (Transverse Direction Orientation): Another important process in BOPP film production, mainly completed by the TDO machine with complex structure including oven, clamp, chain, guide rail, and lubrication system.
    What Kind of Rubber Rolls We Can Supply
    Huatao starts from the roller core structure and its corresponding processing technology to optimize user requirements. We can supply all rubber rollers required for BOPP film production line including:
    fresh
  6. Water removal roller
  7. MDO nip roller
  8. Corona roller
  9. Corona nip roller
  10. PRS product nip roller
  11. Winding roller (contact roller, tracking roller)
  12. Spreader roller
  13. Slitter roller
  14. MDO Nip Roller Specifications
    | cls
    Product name MDO Nip roller
    Shell material 45# steel
    Ruber material Silicon Rubber, HNBR
    Rub hardness 60-80 Shore A
    About Us
    Huatao Group was founded in 2008. We are a professional and leading supplier of various rollers for paper machine, corrugator, rubber & plastic industry, nonwoven fabric industry over 15 years of experience.
    <938 class="pd-text">Paper Industry: forming roller, vacuum couch roller, dandy roller, breast roller, rubber press roller, stone press roller, rubber roller, dryer cylinder, size press roller, calender roller, pope reel roller, spreader roller, embossing roller.
< Eck class="pd-text">Plasticastic & Rubber industry: chill roller, MDO preheating roller, MDO nip roller, MDO stretching roller, PRS cooling roller, corona treater roller, corona treatment nip roller, flame treatment roller, CFRP contact roller, CFRP tension roller, CFRP nip roller, winding core, coating drum, cooling drum, spreader roller, anilox roller, calender roller, embossing roller.
Nonwoven fabric industry: cylinder roller, doffer roller, CFRP guide roller,-embossing roller, cooling roller, spreader roller.
With a strong commitment to innovation, reliability, and customer satisfaction, Huatao Group has become a trusted provider in the industry and our products have been exported to more than 96 countries.
